Automatic Paint Spary Gun Cleaner

Name: Automatic Paint Spary Gun Cleaner
Brand: Dongguan Hetair Intelligent Equipment Co., Ltd.
Rating: 4.2 (3 reviews)

It is an automated cleaning device specifically designed for the painting industry, used to efficiently clean automatic spray guns (atomizers) during the coating process. The equipment utilizes automated program control, combined with brush scrubbing, high-pressure rinsing, solvent cleaning, and rapid drying functions, to quickly remove residual paint, solvent, and other contaminants from the spray gun nozzle.

Quote Now

Automatic Paint Spray Gun Cleaner Features

Efficient Cleaning Performance – Effectively removes paint residue and contaminants from both the internal and external parts of the spray gun, extending its lifespan and ensuring consistent coating quality.
User-Friendly Operation – Simply place the spray gun into the cleaner, set the parameters, and start—no manual disassembly or scrubbing required, reducing labor intensity.
Eco-Friendly & Energy-Saving – Some models feature solvent recovery and recycling systems to minimize waste and reduce environmental impact.

Automatic Paint Spray Gun Cleaner Specifications

Specifications	HT-CCV-3.0
Model	HT-Clean Gun HD001
Technical Parameters
Cleaning Air Pressure	2-4 bar
Cleaning Agent Pressure	3-4 bar
Cleaning Agent Switch Valve Pressure	3-5 bar
Cleaning Medium	Water, Solvent, and Air

Core Advantages

Efficient Cleaning, Time-Saving

Multi-stage cleaning process (main wash, rinse, drying) significantly reduces manual cleaning time, with a single cleaning cycle completed in seconds, shortening cycle time.

Reduces downtime, increasing production time and improving efficiency.

Supports multiple cleaning modes (Quick wash, deep clean) to accommodate different paint types (water-based, solvent-based, UV paint, etc.).

Intelligent Operation, Reduced Labor Costs

Fully automated control with remote operation, eliminating the need for dedicated personnel and reducing human intervention and errors.

Integrates with automated painting management processes, allowing customizable cleaning parameters (time, pressure, flow rate, etc.) and storing multiple presets for easy switching.

Eco-Friendly & Energy-Efficient, Minimized Waste

Recyclable cleaning solvents with extremely low consumption, reducing material costs.

Enclosed design prevents secondary pollution and minimizes solvent evaporation, meeting environmental standards and improving workshop conditions.

High Compatibility & Stability

Compatible with mainstream automatic spray guns, ensuring broad applicability.

Anti-static brush design thoroughly and safely cleans air caps, nozzles, and the entire gun head.

Constructed with corrosion-resistant materials (Stainless steel, PTFE seals，etc.), ensuring long-term durability and low failure rates.
